PVC Layflat Hose
Color: Blue, Brown, Yellow, Red, Green etc
Working Temperature: -10℃- 60℃
Standard Length: 50M/10M
Delivery Period: 30-45 Days
Assembled with Camlock Coupling/Pin Lug Coupling/Bauer Coupling
Delivery Port: Ningbo, Shanghai
Manufacturing Capacity: 100,000KGS/Month
PVC Layflat hose, which is made by strong dacron that coated with synthetic fiber on both sides, has many advantages, such as anti-freezing, anti-pressure, anti-corrosion, easy to move and fold, and long working life. It works better when combined with C+E or Pin Lug. It is suitable for farm, grassland, garden, drought and flood fighting, oil field, mine and construction site.
PVC layflat hose, PVC water hose
1. PVC layflat hose with interlaced hi-strength polyester reinforcement
2. Light weight, good flexibility, and bright color, smooth
3. Flat roll and easy to take, handle and store
4. Capable for keeping the flexibility and elasticity under the low-temperature water
5. Resistant to abrasion and corrosion, hi-pressure and terrible weather.
Technical Parameter
|
Size |
Working Pressure |
Burst Pressure |
|
|
(Inch/mm) |
(Bar) |
(Bar) |
|
|
1" |
25.4±1.0 |
4/6/8 |
12/18/24 |
|
1-1/4" |
31.8±1.0 |
4/6/8 |
12/18/24 |
|
1-1/2" |
38.1±1.0 |
4/6/8 |
12/18/24 |
|
2" |
50.3±1.0 |
4/6/8 |
12/18/24 |
|
2-1/2" |
63.5±1.0 |
4/6/8 |
12/18/24 |
|
3" |
76.2±1.5 |
4/6/8 |
12/18/24 |
|
4" |
101.6±2.0 |
4/6/8 |
12/18/24 |
|
5" |
127±2.0 |
4/6/8 |
12/18/24 |
|
6” |
152.4±2.0 |
3/4/6 |
9/12/18 |
|
8” |
203.2±3.0 |
3/4/6 |
9/12/18 |
|
10” |
254±3.0 |
3/4 |
9/12 |
